Designing the diameter and pitch of a horizontal screw conveyor involves considering several critical parameters to ensure efficient operation. Here's a step-by-step guide to help you calculate these factors:
Refer to standard screw conveyor diameters and select a preliminary size based on conveying capacity. Common diameters are 6, 9, 12, 14, 16, 18, 20, and 24 inches.
Use the following formula to estimate screw capacity: \[ Q = (D^2 \times P \times N \times C) / 60 \] Where:
Consider the bulk density of the material: \[ Capacity{actual} = Q{screw} \times Bulk Density \]
The pitch of the screw is typically equal to the diameter for standard materials, but it can vary.
Use horsepower calculations to ensure the motor can handle the load. This involves friction and material handling considerations.
Check for any surges, material buildup, and desired feed rates. Adjust the conveyor diameter and pitch if necessary.
Let’s say we want to design a screw conveyor for a capacity of 500 ft³/hr, using a material with a bulk density of 50 lb/ft³, and we preliminarily select a 12-inch diameter screw operating at 60 RPM with a pitch equal to the diameter:
Preliminary Capacity Calculation: \[ Q = (D^2 \times P \times N \times C) / 60 \] \[ Q = (12^2 \times 12 \times 60 \times 0.5) / 60 \] \[ Q = (144 \times 12 \times 60 \times 0.5) / 60 \] \[ Q = 864 ft³/hr \] Here, 0.5 is an example factor for illustration purposes.
Considering Bulk Density Adjustments: \[ Capacity{actual} = Q \times Bulk Density \] \[ Capacity{actual} = 864 \times 50 \] \[ Capacity_{actual} = 43200 lb/hr \]
This example simplifies some complexities and assumes general material behavior. Always consult design guides and standards specific to the industry and material handled for precise calculations.
For more accurate and tailored screw conveyor designs, consider specific factors like material abrasiveness, operating conditions, feeder types, and professional software or consultations.
