How to check vibration screens amplitude

To check the amplitude of vibration screens, follow these detailed steps:

Step-by-Step Guide:

  1. Turn Off the Machine: Ensure the vibration screen is off and has come to a complete stop before beginning any measurements.

  2. Select a Measurement Method: There are several methods to measure amplitude:

    • Stroke Plate: A stroke plate attached to the screen can visually show the amplitude by the movement of an indicator.
    • Dial Gauge: Place a dial gauge on the screen frame where it will not affect the oscillation.
    • Accelerometer and Data Logger: Attach an accelerometer to the screen frame to digitally record the vibration.

  3. Position the Measuring Instrument:

    • Stroke Plate: Position the stroke plate so the pointer or marker is on the edge of the stroke scale.
    • Dial Gauge: Attach the magnetic base of the dial gauge firmly to a part of the structure and adjust the needle to rest against the screen.
    • Accelerometer: Securely attach the accelerometer to the frame of the screen, ensuring it's in the correct orientation as per the manufacturer’s instructions.

  4. Turn On the Machine: Power the vibrating screen and let it reach its normal operational speed.

  5. Record Readings:

    • Stroke Plate: Observe the scale as the machine operates, noting the maximum displacement.
    • Dial Gauge: Observe the gauge's needle to measure the peak-to-peak distance (the amplitude).
    • Accelerometer: Use the data logger to collect and analyze the vibration data.

  6. Calculate the Amplitude:

    • Stroke Plate: Direct reading from the scale shows the amplitude.
    • Dial Gauge: The difference between the highest and lowest needle position is the amplitude.
    • Accelerometer: The software accompanying the data logger will analyze and display the amplitude.

  7. Turn Off the Machine and Analyze Data: After taking the measurements, turn off the machine and compare your readings to the manufacturer’s specified values. Ensure that the amplitude falls within acceptable limits, as deviations might indicate potential issues.

Safety Considerations:

  • Always follow safety protocols and make sure the machine is properly shut down before attaching any instruments.
  • Wear appropriate Personal Protective Equipment (PPE).

Tips:

  • Regular checks can help in maintaining the efficiency of the vibrating screen and prevent unexpected downtime.
  • Document all measurements for future reference and trend analysis.

This systematic approach ensures accurate measurement of the screen's amplitude and enables proactive maintenance.
