Need: We want Blister Copper Beneficiation Plant & improve upon Recoveries & purities of metal
First by a coarse grinding, roughing, scavenging, and then rough concentrate regrinding recleaner get high-grade copper concentrate and concentrate. Rough grinding -200 mesh about 45% to 50% and then pulverized -200 mesh occupy about 90% to 95%.
| NO. | Equipment | Model | Number |
|---|---|---|---|
| I | Hopper | LC7 | 1 |
| II | Vibrating Feeder | F5X1660 | 1 |
| III | Vibrating Feeder | GZD1200X2000 | 1 |
| IV | Jaw Crusher | C6X160 | 1 |
| V | Cone Crusher | HST250(S1)*2,HPT500(M)*3 | 5 |
| VI | Vibrating Screen | S5X3072-2*7,S5X2760-2 | 8 |
| VII | Iron-remover | RCYD-12 | 1 |
| NO. | Name | Length(m) | Number |
|---|---|---|---|
| B1 | B1000 | 25 | 1 |
| B2 | B1000 | 25 | 1 |
| B3 | B650 | 8+65+26 | 1 |
| B4 | B1400 | 40 | 1 |
| B5 | B1200 | 25+27 | 1 |
| B6 | B1200 | 32 | 1 |
| B7 | B1400 | 40+90+20 | 1 |
| B8 | B1200 | 40+38 | 1 |
| B9 | B1200 | 36+50+26 | 1 |
| B10 | B1000 | 9+42+26 | 1 |
| B11 | B800 | 11+42+26 | 1 |
| B12 | B1000 | 11+43+26 | 1 |
